1826364 by phoenix contact

1826364

Phoenix Contact

PCB connector - nominal current: 12 A - rated voltage (III/2): 320 V - nominal cross section: 2.5 mm² - number of positions: 10 - pitch: 5.08 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1826364 is a PCB connector designed for reliable and secure electrical connections. With a nominal current of 12 A and a rated voltage of 320 V (III/2), this connector is suitable for various applications.Featuring a 2.5 mm² nominal cross section and 10 positions, this PCB connector offers ample space for multiple wire connections. The 5.08 mm pitch ensures easy and accurate alignment of the wires, simplifying installation and maintenance processes.Designed with a screw connection method with tension sleeve, this connector guarantees a secure and durable connection. The green color adds visual distinction, making it easy to identify and differentiate from other connectors.With a contact surface made of tin, this PCB connector offers excellent electrical conductivity and corrosion resistance. It ensures a reliable and long-lasting connection, providing peace of mind for your electrical applications.

Search Keywords: 1826364

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1826364
RoHS:
Yes
HTS:
8536694040
COO:
PL
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Terminal Block
Mounting:
Cable Mount
Gender:
F
Termination Method:
Screw
Pitch:
5.08 mm
Number of Circuits:
10
Maximum Voltage Rating:
320 V
Maximum Current Rating:
12 A
Wire Size:
12-24 AWG
Operating Temperature:
-40 to 100 °C

IN STOCK: 0

Minimum Order: 5

Factory Lead-Time 13 Weeks

Price (CAD)

Qty
Unit Price
5
$21.122
25
$18.859
50
$17.503
100
$16.565
250
$16.318
500
$15.917
1,000 +
$15.671
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
