1828553 by phoenix contact

1828553

Phoenix Contact

PCB connector - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 8 - pitch: 3.81 mm - connection method: Screw connection with tension sleeve - color: green - contact surface: Tin ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1828553 is a PCB connector designed for reliable connections in electronic circuits. With a nominal current rating of 8 A and a rated voltage of 160 V (III/2), this connector ensures safe and efficient power transmission.Featuring a nominal cross section of 1.5 mm², the connector is capable of accommodating various wire sizes. It offers 8 positions and a pitch of 3.81 mm, allowing for easy integration into PCB layouts.The connection method employed is a screw connection with a tension sleeve, ensuring secure and stable connections. The connector is color-coded in green for easy identification and comes with a tin contact surface, offering excellent conductivity and corrosion resistance. Overall, the PHOENIX CONTACT part 1828553 is a high-quality PCB connector that meets industry standards and provides reliable performance in various applications.

Search Keywords: 1828553

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1828553
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Type:
Terminal Block
Mounting:
Panel Mount
Gender:
F
Termination Method:
Screw
Pitch:
3.81 mm
Number of Circuits:
8
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Wire Size:
16-28 AWG
Operating Temperature:
N/A

IN STOCK: 175

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 4 Weeks

Price (CAD)

Qty
Unit Price
5
$15.206
25
$13.568
50
$12.603
100
$12.082
250
$11.760
500
$11.454
1,000 +
$11.286
