1844249 by phoenix contact

1844249

Phoenix Contact

PCB headers - nominal current: 8 A - rated voltage (III/2): 160 V - nominal cross section: 1.5 mm² - number of positions: 5 - pitch: 3.5 mm - color: green - contact surface: Tin - mounting: Wave soldering - pin layout: Linear pinning - solder pin [P]: 3.4 mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1844249 is a PCB header designed for various electrical applications. With a nominal current of 8 A and a rated voltage (III/2) of 160 V, this header ensures reliable and efficient power transfer. Featuring a 1.5 mm² nominal cross section, it is capable of handling medium to high currents. Its 5 positions and 3.5 mm pitch provide ample space for wiring and connections, making installations easy and convenient. The header is available in a green color, giving it a sleek and professional look.With a tin contact surface, this header offers excellent conductivity and corrosion resistance, ensuring long-lasting performance. It is suitable for wave soldering mounting, providing secure and stable connections. The linear pinning pin layout allows for easy and straightforward installation.Overall, the PHOENIX CONTACT part 1844249 is a reliable and versatile PCB header that guarantees efficient power transfer and easy installation. Its high-quality construction and user-friendly design make it an ideal choice for various electrical projects.

Search Keywords: 1844249

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1844249
RoHS:
Yes
HTS:
8536694040
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
250
Type:
Shrouded Header (4 Sides)
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
3.5 mm
Number of Contacts:
5
Maximum Voltage Rating:
160 V
Maximum Current Rating:
8 A
Termination Method:
Solder
Operating Temperature:
N/A

IN STOCK: 1,000

Ships today, if you order in

Minimum Order: 10

Factory Lead-Time 11 Weeks

Price (CAD)

Qty
Unit Price
10
$3.308
100
$2.435
250
$2.404
500
$2.389
1,000 +
$2.374
