1984659 by phoenix contact
Image is representational - see mfr. specs

1984659

Phoenix Contact

PCB terminal block - nominal current: 17.5 A - rated voltage (III/2): 200 V - nominal cross section: 1.5 mm² - pitch: 3.5 mm - number of positions: 6 - connection method: Screw connection with wire protector - mounting: Wave soldering - conductor/PCB connection direction: 0 ° - color: green - Pin layout: Linear pinning - Solder pin [P]: 4.5 mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 1984659 is a PCB terminal block with a compact design for efficient wire connections. With a nominal current of 17.5 A and a rated voltage of 200 V, it offers reliable performance. The terminal block has a nominal cross-section of 1.5 mm² and a pitch of 3.5 mm, making it compatible with various applications.Featuring 6 positions, this terminal block utilizes a screw connection with a wire protector to ensure secure and stable connections. It can be easily mounted using wave soldering. The conductor/PCB connection direction is set at 0°, allowing for smooth and straightforward installation.Distinguished by its vibrant green color, this terminal block incorporates a linear pinning pin layout for easy identification and arrangement. Additionally, the solder pin measures 4.5 mm in length, providing ample space for efficient soldering.

Search Keywords: 1984659

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1984659
Alias/AKA:
1984659, PT-1-5/-6-3-5-H
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
3.5 mm
Number of Circuits:
6
Maximum Voltage Rating:
160 V
Maximum Current Rating:
17.5 A
Wire Size:
16-26 AWG
Operating Temperature:
N/A

IN STOCK: 430

Can Ship immediately

Minimum Order Quantity: 100

Multiple: 100

Factory Lead-Time 2 Weeks

Price (USD)

Qty
Unit Price
100
$1.24
300
$1.22
500
$1.19
1,000
$1.16
2,500
$1.14
5,000
$1.12
7,500 +
$1.11
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

0804073

Marker card - Card - white - labeled - Horizontal: consecutive numbers 1 ... 10 - 11 ... 2 ...

1205037

Screwdriver - slot-headed - VDE insulated - size: 0.4 x 2.5 x 80 mm - 2-component grip - w ...
