1985001 by phoenix contact

1985001

Phoenix Contact

PCB terminal block - nominal current: 8 A - rated voltage (III/2): 250 V - nominal cross section: 1.5 mm² - pitch: 3.5 mm - number of positions: 6 - connection method: Push-in spring connection - mounting: Wave soldering - conductor/PCB connection direction: 45 ° - color: green - Pin layout: Linear pinning - Solder pin [P]: 3.6 mm. Soldering legs in front area - one-rowed ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

This PCB terminal block from PHOENIX CONTACT (part 1985001) is designed for excellent electrical connections in compact spaces. With a nominal current of 8 A and a rated voltage of 250 V, it is suitable for various applications. The terminal block has a nominal cross-section of 1.5 mm² and a pitch of 3.5 mm, with 6 positions available for easy wiring. The push-in spring connection method ensures secure and quick installation, while the 45° conductor/PCB connection direction allows for efficient routing. The green color and linear pinning layout make identification and assembly straightforward. The terminal block is designed for wave soldering mounting, with solder pin legs measuring 3.6 mm for convenient soldering. Overall, this one-rowed terminal block is a reliable solution for your PCB connectivity needs.

Search Keywords: 1985001

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1985001
RoHS:
Yes
HTS:
8536904000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
160
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
3.5 mm
Number of Circuits:
6
Maximum Voltage Rating:
250 V
Maximum Current Rating:
8 A
Wire Size:
16-24 AWG
Operating Temperature:
-40 to 100 °C

IN STOCK: 0

Manufacturer Stock: 991   can ship 12/1/25

On Order: 640   can ship 12/1/25

Minimum Order: 160

Multiple: 160

Factory Lead-Time 4 Weeks can ship 12/18/25

Price (USD)

Qty
Unit Price
160
$1.061
320
$1.045
640
$1.030
1,120
$0.947
2,560
$0.932
5,120
$0.909
7,520
$0.896
10,080 +
$0.883
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes
