1985234 by phoenix contact
Image is representational - see manufacturer specifications
Phoenix Contact Authorized Distributor

1985234

The 1985234 is a 6-position, two-row PCB terminal block with a 3.5 mm pitch, featuring a push-in spring connection for wave soldering. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 1985234 is a 6-position PCB terminal block designed for secure wire-to-board connections. It is rated for a nominal current of 8 A and a nominal voltage of 400 V, with a compact 3.5 mm pitch. The component features a time-saving, tool-free push-in spring connection and is mounted via wave soldering, with a conductor-to-PCB connection direction of 45°. Its two-rowed design with offset soldering legs allows for multi-row arrangements, making it ideal for applications requiring high-density connections on the printed circuit board.

Search Keywords: 1985234

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
1985234
Alias/AKA:
1985234
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
160
Type:
PC Terminal Block
Mounting:
Through Hole
Gender:
N/A
Termination Method:
Solder
Pitch:
3.5 mm
Number of Circuits:
6
Maximum Voltage Rating:
250 V
Maximum Current Rating:
8 A
Wire Size:
16-24 AWG
Operating Temperature:
N/A

IN STOCK: 1,921

Can Ship immediately

Minimum Order Quantity: 160

Multiple: 160

Factory Lead-Time 4 Weeks

Price (USD)

Qty
Unit Price
160
$0.892
320
$0.883
640
$0.874
1,120
$0.872
2,560
$0.870
5,120
$0.867
7,520
$0.865
10,080 +
$0.863
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
