2320092

Phoenix Contact

Primary-switched QUINT DC/DC converter for DIN rail mounting with SFB (Selective Fuse Breaking) Technology - input: 24 V DC - output: 24 V DC/10 A ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

2320092 is a QUINT mini DC/DC converter which alter the voltage level, regenerate the voltage at the end of long cables or enable the creation of independent supply systems by means of electrical isolation. It has a nominal input voltage range of 18 to 32 VDC, nominal output voltage of 24VDC, nominal output current of 10A, selective fuse breaking of 60A (12 ms) and efficiency of 92% or higher. The product can be mounted in horizontal DIN rail, and can also be connected in series or parallel. Connection at input and output is through M3 pluggable screw connection. Product's dimensions are 48mm x 130mm x 125mm (wxhxd).

Search Keywords: 2320092

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
2320092
RoHS:
Yes
HTS:
8504407012
COO:
IN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Family:
2320092
Dimension:
125 x 48 x 130 mm
Input Voltage:
14 to 32 V

IN STOCK: 9

Ships today, if you order in

Manufacturer Stock: 85   can ship 12/8/25

Factory Lead-Time 10 Weeks can ship 1/30/26

Price (CAD)

Qty
Unit Price
1
$753.125
3 +
$715.470
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
Older Equivalent
2866378
2866378
VIEW PRODUCT
