Image is representational - see mfr. specs

2941154

The 2941154 is a 6.2 mm wide relay terminal block with a soldered-in miniature relay, featuring a 1 N/O contact and a 24 V AC/DC input voltage. ...

Datasheet

RoHS Compliant

Certificate of Compliance Guarantee

DESCRIPTION

The 2941154 is a relay terminal block designed for switching small to medium loads using a soldered-in miniature relay. It operates with a nominal input voltage of 24 V AC/DC and provides a single normally open (N/O) double contact made of AgNi with hard gold plating. This 2-layer contact design supports universal applications with currents from 1 mA up to a limiting continuous current of 5 A. The module ensures safety with 2 kVrms electrical isolation between the input and output. Its compact 6.2 mm width allows for high-density mounting on NS 35/7.5 DIN rails, saving panel space and reducing wiring complexity.

Product Highlights:

Potential Applications:

Search Keywords: 2941154

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Phoenix Contact

Part No:

2941154

Alias/AKA:

2941154, DEK-REL-24/O/1

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536410060

COO:

ECCN:

EAR99
