3001501

Name: 3001501
Brand: Phoenix Contact
SKU: 12156810
Price: 2.98 USD
Availability: InStock

The 3001501 is a gray, DIN rail mountable feed-through terminal block with a screw connection method. ...

View Datasheet

Ask the Datasheet

RoHS Compliant

Certificate of Compliance

DESCRIPTION

The 3001501 is a feed-through terminal block that provides two screw connections for wiring. It is rated for a nominal voltage of 800 V and a nominal current of 24 A. This terminal block accommodates a conductor cross-section ranging from 0.2 mm² to 4 mm² (AWG 24-12). Constructed from gray polyamide (PA) insulating material with a V0 flammability rating, the block has a compact width of 5.2 mm. Its universal foot allows for versatile mounting on NS 32, NS 35/15, and NS 35/7,5 DIN rails, making it ideal for various industrial control and potential distribution applications.

Product Highlights:

Potential Applications:

Search Keywords: 3001501

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Phoenix Contact

Part No:

3001501

Alias/AKA:

3001501

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8536904000

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
