3036534 by phoenix contact

3036534

Phoenix Contact

Component terminal block - with integrated diode - nom. voltage: 800 V - nominal current: 0.5 A - connection method: Spring-cage connection - cross section: 0.08 mm² - 4 mm² - AWG: 28 - 12 - length: 72 mm - width: 5.2 mm - color: gray - mounting: NS 35/7,5 - NS 35/15 ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 3036534 is a component terminal block with an integrated diode, designed for use in electrical applications. With a nominal voltage of 800 V and a nominal current of 0.5 A, this terminal block features a spring-cage connection method and can accommodate wire cross sections ranging from 0.08 mm² to 4 mm² (AWG 28-12). Measuring 72 mm in length and 5.2 mm in width, the terminal block is colored gray for easy identification. It is designed for mounting on NS 35/7,5 or NS 35/15 rails, providing a reliable and secure connection for various electrical components.

Search Keywords: 3036534

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
3036534
RoHS:
Yes
HTS:
8536904000
COO:
PL
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Contact Plating:
N/A
Contact Material:
N/A
Dimension:
72mm x 5.2mm x 44 mm
Housing Color:
Gray
Body Orientation:
N/A
Maximum Current Rating:
0.5 A
Housing Material:
Polyamide
Gender:
F
Family:
3036534

IN STOCK: 50

Can Ship immediately

Minimum Order: 3

Factory Lead-Time 2 Weeks

Price (CAD)

Qty
Unit Price
3
$14.255
25
$13.963
50 +
$13.686
