3036563 by phoenix contact
Image is representational - see mfr. specs

3036563

Phoenix Contact

The 3036563 is a lever-type fuse modular terminal block designed for 5 x 20 mm G-type fuses, featuring an LED indicator for voltages up to 250V. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 3036563 is a lever-type fuse modular terminal block designed to hold 5 x 20 mm G-type fuses and provide circuit protection. It has a nominal voltage of 250V, a nominal current of 6.3A, and features an integrated LED that indicates status for a voltage range of 110V to 250V AC/DC. The block utilizes a spring-cage connection method that accepts conductor cross-sections from 28 to 10 AWG. Constructed from black polyamide (PA) insulating material with a V0 flammability rating, it has an extremely compact 6.2 mm width. This component is ideal for industrial control panels and automation systems where space is limited and reliable, easily diagnosable overcurrent protection is required.

Search Keywords: 3036563

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
3036563
Alias/AKA:
3036563, ST-4-HESILA-250-(5X20)
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
TR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Gender:
N/A
Contact Plating:
N/A
Dimension:
61.5mm x 6.2mm x 70mm
Contact Material:
N/A
Family:
3036563
Body Orientation:
N/A
Housing Color:
Black

IN STOCK: 65

Can Ship immediately

Manufacturer Stock: 297   can ship 5/4/26

Minimum Order Quantity: 2

Factory Lead-Time 5 Weeks can ship 5/27/26

Price (USD)

Qty
Unit Price
2
$15.98
25
$15.18
50 +
$14.42
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
