3044160
Phoenix ContactFeed-through terminal block - nom. voltage: 1000 V - nominal current: 57 A - connection method: Screw connection - number of connections: 2 - cross section: 0.5 mm² - 16 mm² - AWG: 20 - 6 - width: 10.2 mm - height: 46.9 mm - color: gray - mounting type: NS 35/7,5 - NS 35/15 ...
DESCRIPTION
The UT 10 is a 2-position 1-level grey Feed-through Terminal Block with a polyamide insulator, the screw connection and the NS 35/7,5, NS 35/15 mounting. This 3044160 terminal lock has the compact design enables user-friendly wiring in a small amount of space. The large wiring space enables the connection of solid and stranded conductors without ferrules, even above the nominal cross section. The cable entry funnel enables the use of conductors with ferrules and plastic collars within the nominal cross section. It accepts 20 to 6AWG wire range. Half-sine shock form Optimum screwdriver guidance through closed screw shafts Multi-conductor connection offers maximum flexibility and wiring density 10mm Stripping length UL94V-0 Flammability rating Applications Industrial, Automation & Process Control
Search Keywords: 3044160
SPECIFICATIONS
IN STOCK: 4,648
Can Ship immediately
Manufacturer Stock: 44,049 can ship 12/5/25
Minimum Order: 10
Factory Lead-Time 4 Weeks can ship 12/18/25
Tools/3D Models
Product Guides
Datasheet
Product Changes
PCN - 01-Jan-2015 - INTRODUCTION OF 2D BARCODING
