3046184 by phoenix contact

3046184

Phoenix Contact

Feed-through terminal block - nom. voltage: 800 V - nominal current: 32 A - connection method: Screw connection - number of connections: 2 - cross section: 0.14 mm² - 6 mm² - AWG: 26 - 10 - width: 6.2 mm - color: gray - mounting type: NS 35/7,5 - NS 35/15 ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Phoenix Contact UT Series Standard Terminal Blocks with screw connections feature maintenance-free conductor connections with the Reakdyn principle. With this principle, terminal block screws are resistant to loosening during high vibration. FEATURES Clamp all types of copper cables without pretreatment - also supports ferruled conductors Support multi-conductor connections - two conductors with the same cross-section can be safely terminated High contact forces and large contact surfaces - conductor cross-sections of up to 500kcmil (240mm2) can be wired and maintain a gas-tight connection with long-term reliability. Number of Positions 2 Number of Levels 1 Terminal - Width 6.2mm Termination Style Screw Current - IEC 32A Voltage - IEC 800V Current - UL 30A Voltage - UL 600V Wire Gauge or Range - AWG 10-26 AWG Wire Gauge or Range - mm² 0.14-6mm²

Search Keywords: 3046184

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
3046184
RoHS:
Yes
HTS:
8536904000
COO:
DE
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Body Orientation:
Straight

IN STOCK: 1,812

Can Ship immediately

Manufacturer Stock: 48,765   can ship 12/5/25

Minimum Order: 20

Factory Lead-Time 4 Weeks can ship 12/18/25

Price (CAD)

Qty
Unit Price
20
$1.838
50 +
$1.745
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
