3208964 by phoenix contact
Image is representational - see mfr. specs

3208964

Phoenix Contact

Fuse modular terminal block - fuse type: Flat - connection method: Push-in connection - cross section: 0.2 mm²- 6 mm² - AWG: 24 - 10 - nominal current: 10 A - nom. voltage: 24 V - width: 6.2 mm - fuse type: Type F (miniature) - mounting type: NS 35/7,5 - NS 35/15 - color: black ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PHOENIX CONTACT part 3208964 is a Fuse modular terminal block designed for use with flat fuses. Featuring a push-in connection method, this terminal block is suitable for wire cross sections ranging from 0.2 mm² to 6 mm² (AWG 24-10). With a nominal current of 10 A and a nominal voltage of 24 V, this terminal block has a compact width of 6.2 mm and accommodates Type F (miniature) fuses. It is designed for mounting on NS 35/7.5 or NS 35/15 DIN rails and comes in a sleek black color. Ideal for various industrial applications, this terminal block ensures safe and reliable fuse connections.

Search Keywords: 3208964

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Phoenix Contact
Part No:
3208964
Alias/AKA:
3208964, PT-4-FSI/F-LED-24
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
PL
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Family:
3208964
Contact Material:
N/A
Contact Plating:
N/A
Gender:
N/A
Housing Color:
Black
Body Orientation:
N/A
Dimension:
56mm x 6.2mm x 44 mm

IN STOCK: 148

Can Ship immediately

Manufacturer Stock: 5,515   can ship 5/4/26

Minimum Order Quantity: 2

Factory Lead-Time 5 Weeks can ship 5/27/26

Price (USD)

Qty
Unit Price
2
$17.08
25
$16.22
50 +
$15.41
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
