PTSA-1-5/-5-3-5-Z
Phoenix ContactPCB terminal block - nominal current: 8 A - rated voltage (III/2): 400 V - nominal cross section: 1.5 mm² - pitch: 3.5 mm - number of positions: 5 - connection method: Push-in spring connection - mounting: Wave soldering - conductor/PCB connection direction: 45 ° - color: green - Pin layout: Zigzag pinning M - Solder pin [P]: 3.6 mm. Offset soldering legs - two-rowed ...
DESCRIPTION
PCB terminal block - nominal current: 8 A - rated voltage (III/2): 400 V - nominal cross section: 1.5 mm² - pitch: 3.5 mm - number of positions: 5 - connection method: Push-in spring connection - mounting: Wave soldering - conductor/PCB connection direction: 45 ° - color: green - Pin layout: Zigzag pinning M - Solder pin [P]: 3.6 mm. Offset soldering legs - two-rowed
Search Keywords: PTSA15535Z
SPECIFICATIONS
IN STOCK: 1,264
Ships today, if you order in
Manufacturer Stock: 236 can ship 5/29/26
Minimum Order Quantity: 180
Multiple: 180
Factory Lead-Time 4 Weeks can ship 6/11/26
Datasheet
