RAD-900-ANT-OMNI-2-N

Omnidirectional antenna - 868 MHz / 900 MHz - gain: 2 dBi - polarization: linear - opening angle: h/v 360°/50° - degree of protection: IP66 - connection: N (female) - for control cabinet mounting (optional wall mounting) ...

Datasheet

RoHS Compliant

DESCRIPTION

Omnidirectional antenna, 868 MHz / 900 MHz, gain: 2 dBi, polarization: linear, opening angle: h/v 360°/50°, for control cabinet mounting (optional wall mounting) Connection Type Type N (female) Diameter 1.42" (36mm) Frequency 868-960 MHz Height 3.31" (84mm) Impedance 50 Ohms Material Xenoy 5720U-7014 (Antenna housing) Mounting Type Control cabinet Polarization Linear vertical Gain 2.15 dBi IP Rating IP66

Product Highlights:

Potential Applications:

Search Keywords: RAD900ANTOMNI2N

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

Phoenix Contact

Part No:

RAD-900-ANT-OMNI-2-N

RoHS:

Yes

HTS:

8517790000

COO:

ECCN:

EAR99
