5145 by pomona electronics

5145

Pomona Electronics

The 5145 is an encapsulated, low-profile double banana plug shorting bar. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee
Can only ship inside the US. If exported, the warranty will be void.

DESCRIPTION

The 5145 is a completely insulated, low-profile double banana plug shorting bar designed to mate with standard double banana jacks. It is rated for a current of 15 Amperes, has an installed resistance of less than 1.5 milliohms, and operates at temperatures up to +50°C. The device features nickel-plated brass plug bodies and a shorting bar, with beryllium copper springs for reliable contact. Its clear polypropylene insulation is molded over the assembly and includes a finger ridge for easy insertion and removal, making it ideal for shorting circuits in test and measurement setups.

Search Keywords: 5145

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Pomona Electronics
Part No:
5145
Alias/AKA:
1632560
Unit of Measure:
Per Each
RoHS:
Yes
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5

IN STOCK: 244

Ships today, if you order in

Minimum Order Quantity: 5

Multiple: 5

Factory Lead-Time 2 Weeks

Price (USD)

Qty
Unit Price
5
$14.26
25
$13.53
50
$12.43
100
$11.87
250
$11.59
500
$11.18
1,000 +
$11.14
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
