782XBXC-12D by schneider electric-legacy relays
Image is representational - see manufacturer specifications
Schneider Electric-Legacy Relays Authorized Distributor

782XBXC-12D

Power relay - SE Relays - 15A - DPDT - 12 VDC - clear cover ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued & Replaced
Certificate of Compliance

DESCRIPTION

The Magnecraft / Schneider Electric 782XBXC-12D is a high-quality electromechanical relay designed for optimal performance and durability. With a coil voltage of 12VDC and a resistance of 160 Ohm, this relay is suitable for a wide range of applications. It features a DPDT (Double Pole Double Throw) configuration, which allows for versatile switching options. Measuring at approximately 27.9 x 21 x 42.9mm, this relay is compact and space-saving, making it ideal for various industrial and commercial settings. It is capable of handling a maximum current of 15A, ensuring reliable power switching. The 782XBXC-12D relay is designed to be used with a socket, providing easy installation and maintenance. With the trusted brand of Magnecraft / Schneider Electric, you can rely on the quality and performance of this power relay for your application needs.

Search Keywords: 782XBXC12D

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
782XBXC-12D
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
10
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
15 A
Mounting:
Socket
Termination Style:
0.187Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 70 °C
Coil Resistance:
160 Ohm
Life Cycle:
Discontinued & Replaced
  This product is discontinued, but still in stock

IN STOCK: 773

Can Ship immediately

Minimum Order Quantity: 10

Multiple: 10

Price (USD)

Qty
Unit Price
10
$22.72
30
$21.00
50
$20.94
100
$20.33
250
$19.73
500
$15.83
1,000 +
$15.79
