782XBXM4L-24A by schneider electric-legacy relays
Image is representational - see mfr. specs

782XBXM4L-24A

Schneider Electric-Legacy Relays

Power Relay - General Purpose Relays - DPDT - LED clear cover - lock push button - faston terminals - 15A - 12V DC - 2NO + 2NC

Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued & Replaced
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Power Relay - General Purpose Relays - DPDT - LED clear cover - lock push button - faston terminals - 15A - 12V DC - 2NO + 2NC

Search Keywords: 782XBXM4L24A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
782XBXM4L-24A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Relay Construction:
Non-Latching
AC Coil Voltage:
24 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPDT
Maximum Current Rating:
15 A
Mounting:
Socket
Termination Style:
0.187Quick Connect
Push to Test Button:
Yes
Led Indicator:
Yes
Operating Temperature:
-40 to 70 °C
Coil Resistance:
180 Ohm
Life Cycle:
Discontinued & Replaced
  This product is discontinued, but still in stock

IN STOCK: 95

Can Ship immediately

On Order: 50   can ship 5/29/26

Minimum Order Quantity: 10

Multiple: 10

Price (USD)

Qty
Unit Price
10
$16.03
30
$15.83
50
$15.64
100
$14.49
250
$13.39
500
$13.32
1,000 +
$13.26
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
RECOMMENDED REPLACEMENT
W78ARNCSX-6
W78ARNCSX-6
VIEW PRODUCT

Tools/3D Models

Product Guides

Accessories

70-782D8-1

Conn Relay Socket SKT 8 POS Screw ST Panel Mount

70-459-1

Socket - General Purpose Relays - for 782 relays - DPDT - 8 pins - output screw clamp term ...
