782XBXM4L-24D by schneider electric-legacy relays

782XBXM4L-24D

Schneider Electric-Legacy Relays

Power Relay - General Purpose Relays - DPDT - LED clear cover - lock push button - faston terminals - 15A - 24V DC - 2NO + 2NC ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Magnecraft / Schneider Electric 782XBXM4L-24D is a reliable and efficient Electromechanical Relay designed for various industrial applications. This high-quality relay operates at 24VDC and has a contact resistance of 650 Ohms. It features a Double Pole Double Throw (DPDT) configuration, providing versatile switching options. With a compact size of 27.9x21x46.5mm, this relay can be easily installed using the accompanying socket, saving valuable space in your electrical panel. The 782XBXM4L-24D relay is rated for a maximum current of 15A, making it suitable for handling demanding loads. Trust in the power and precision of this Magnecraft / Schneider Electric relay for your control and automation needs.

Search Keywords: 782XBXM4L24D

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Schneider Electric-Legacy Relays
Part No:
782XBXM4L-24D
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
15 A
Mounting:
Socket
Termination Style:
0.187Quick Connect
Push to Test Button:
Yes
Led Indicator:
Yes
Operating Temperature:
-40 to 70 °C
Coil Resistance:
650 Ohm

IN STOCK: 380

Can Ship immediately

Minimum Order: 10

Multiple: 10

Factory Lead-Time 2 Weeks

Price (USD)

Qty
Unit Price
10
$17.850
30
$17.572
50
$17.098
100
$16.367
250
$15.955
500
$15.821
1,000 +
$15.738
Suppliers Standard Package
Log in for special pricing
Click for Quote

Tools/3D Models

Product Guides

Accessories

70-782D8-1

Conn Relay Socket SKT 8 POS Screw ST Panel Mount

70-459-1

Socket - General Purpose Relays - for 782 relays - DPDT - 8 pins - output screw clamp term ...
