CWA2490
Sensata / CrydomSolid State Relay - 90-280 VAC Control - 90 A Max Load - 24-280 VAC Operating - Zero Voltage - LED Status - Panel Mount.
RoHS Compliant
EACH Packaging
Certificate of Compliance Guarantee
DESCRIPTION
The CWA2490 solid state relay has SCR output for heavy industrial loads and removable IP20 touch-safe cover. Dimensions of this relay (with cover) are: 2.32" (58.8mm) x 1.75" (44.5mm) x 1.22" (30.9mm).
Search Keywords: CWA2490
SPECIFICATIONS
Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Sensata / Crydom
Part No:
CWA2490
RoHS:
Yes
HTS:
8536490080
COO:
MX
ECCN:
EAR99
Supplier Standard Pack:
10
Package Type:
EACH
Output Type:
AC
Maximum Output Voltage:
280(RMS) V
Maximum Output Current:
90(RMS) A
Output Device:
SCR
Input Type:
AC
Input Voltage:
280(RMS) V
Mounting:
Screw
Circuit Arrangement:
1 Form A
Dimension:
45.7 x 58.4 x 33 mm
IN STOCK: 23
Can Ship immediately
Factory Lead-Time 16 Weeks
Price (CAD)
Qty
Unit Price
1
$156.900
5
$150.834
10
$147.601
20
$144.646
30
$142.476
50
+
$140.335
CAD Drawing
Datasheet
Selecting a SSR
