134MPCX-3

The 134MPCX-3 is a single-pole, double-throw (SPDT) miniature mercury wetted reed relay with a 24VDC coil. ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 134MPCX-3 is a miniature, SPDT mercury reed relay from the 134 series. It operates with a nominal coil voltage of 24VDC, features a coil resistance of 1400 ohms, and consumes a nominal power of 410 mW. The relay's contacts are rated for a maximum load of 50VA, with a maximum switching capability of 1 Amp at 500VDC and a carry current of 2 Amps. The use of liquid mercury in a hermetically sealed glass tube provides continuously refreshed contact surfaces, resulting in an extremely long electrical life expectancy. This makes the relay ideal for applications requiring high-repetition and reliable switching performance.

Search Keywords: 134MPCX3

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Struthers-Dunn
Part No:
134MPCX-3
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536410020
COO:
IN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1

IN STOCK: 12

Can Ship immediately

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
1
$131.17
5
$129.39
10
$101.09
20
$100.44
50
$68.65
100 +
$59.13
Log in for special pricing

Tools/3D Models

Product Guides
