21XBXPL-120VAC by struthers-dunn

21XBXPL-120VAC

Struthers-Dunn

Electromechanical Relay 120VAC 20ADC/30AAC DPDT (60.3x44.5x82.4)mm Socket General Purpose Relay ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The STRUTHERS-DUNN part 21XBXPL-120VAC is a versatile electromechanical relay designed for various general purpose applications. With a compact size of 60.3x44.5x82.4mm, this relay offers high performance and precision in a small package. It operates at a voltage of 120VAC and can handle currents up to 20ADC and 30AAC. The relay is configured with a DPDT (Double Pole Double Throw) configuration, allowing for flexible and reliable switching control. Additionally, the relay comes with a socket for easy installation and maintenance. Trust STRUTHERS-DUNN for a high-quality, durable, and efficient relay solution.

Search Keywords: 21XBXPL120VAC

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Struthers-Dunn
Part No:
21XBXPL-120VAC
RoHS:
Yes
HTS:
8536490075
COO:
IN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Relay Construction:
Non-Latching
AC Coil Voltage:
120 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPDT
Maximum Current Rating:
30 A
Mounting:
Socket
Termination Style:
Solder
Push to Test Button:
No
Led Indicator:
Yes
Operating Temperature:
-34 to 74 °C

IN STOCK: 100

Can Ship immediately

Factory Lead-Time 12 Weeks

Price (CAD)

Qty
Unit Price
1
$178.168
5
$148.475
10
$137.970
15
$133.607
25
$126.578
50 +
$125.950
