FSM4JSMA

TE Connectivity / Alcoswitch Brand

Switch Tactile OFF (ON) SPST Round Button Gull Wing 0.05A 12VDC 1.57N SMD Bulk ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

FSM4JSMA is a surface-mount tactile switch from the FSMJSMA Series, featuring a 6 mm × 6 mm square footprint designed for compact PCB integration. The switch is constructed with copper alloy silver-plated contacts, a PPS case and actuator button, and a steel tin-plated cover, providing reliable electrical performance with a contact rating of 50 mA at 12 VDC. Key performance characteristics include an initial contact resistance of 100 milliohms maximum, insulation resistance of 100 megohms minimum at 100 VDC, and dielectric strength of 500 VAC for 1 minute. The switch offers an actuator travel of 0.010 inches (0.254 mm) with selectable actuation force options and supports up to 100,000 operating cycles. Operating temperature range is -20°C to +85°C, with solder heat resistance rated for IR soldering per EIA-364-56 Procedure 5 Level 3 at 260°C, making it suitable for automated assembly and consumer electronics applications.

Product Highlights:

  • Switch
  • Tactile
  • Single Pole - Single Throw Configuration (Pole-Throw)
  • Contact Rating = 50mA
  • Operating Function = Off [On]

Search Keywords: FSM4JSMA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
FSM4JSMA
Alias/AKA:
4-1437565-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509033
COO:
KR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
750
Package Type:
Bag
Dimension:
6 x 10 x 5.25 mm
Mounting:
PCB Surface Mount
Pole Throw Configuration:
SPST
Switch Configuration:
Off (On)
Actuator Style:
Round Button
Operating Force:
1.57 N
Contact Rating @ Voltage:
0.05@12VDC A
Illumination Type:
N/R
Body Orientation:
Straight
Termination Style:
Gull Wing
Seal Location:
N/A

IN STOCK: 28,939

Ships today, if you order in

Minimum Order Quantity: 750

Multiple: 750

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
750
$0.1035
1,500
$0.1030
3,000
$0.1020
5,250
$0.1015
10,500
$0.1009
25,500
$0.1004
50,250
$0.0999
100,500 +
$0.0994
Suppliers Standard Package
