MSS4350RG04 by te connectivity / alcoswitch brand
Image is representational - see mfr. specs

MSS4350RG04

TE Connectivity / Alcoswitch Brand

Switch Slide Extended Side Slide 20VAC 20VDC 0.4VA PC Pins Bracket Mount/PCB Through Hole ...

Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

MSS4350RG04 is a make-before-break slide switch from the MSS 4350R series designed for reliable low-level signal switching. It features gold-plated terminal and fixed contacts over nickel plate, with an initial contact resistance of 30 milliohm max and final contact resistance of 100 milliohm max after testing. The switch offers a contact rating of 0.4VA at 20VDC or peak AC, insulation resistance of 1,000 Megohms minimum, and dielectric strength of 500V RMS at sea level. With an actuation force of 600±300 grams and travel of 2.0±0.50 mm, it operates reliably across a temperature range of -20°C to +85°C. This RoHS-compliant switch is suitable for applications requiring precise, low-resistance switching with extended life expectancy of 15,000 cycles minimum.

Search Keywords: MSS4350RG04

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
MSS4350RG04
Alias/AKA:
1825270-2
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536509050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Mounting:
Bracket Mount/PCB Through Hole
Body Orientation:
Right Angle
Actuator Style:
Extended Side Slide
Pole Throw Configuration:
N/A
Switch Configuration:
N/A
Contact Rating @ Voltage:
0.4@20VAC 20VDC A
Contact Plating:
Gold/Nickel
Operating Temperature:
-20 to 85 °C
Termination Style:
PC Pins
Dimension:
22 x 24.1 x 11.5 mm
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 1,158

Ships today, if you order in

Minimum Order Quantity: 15

Price (USD)

Qty
Unit Price
15
$5.35
65
$5.24
150
$5.15
250
$5.05
2,000
$4.94
2,500
$4.60
5,000 +
$4.07
