MTL206N by te connectivity / alcoswitch brand

MTL206N

TE Connectivity / Alcoswitch Brand

Toggle Switch - DPDT - On-On - 6A(AC)/4A(DC), 125VAC/28VDC - 17.00mm Locking Lever Actuator - Non-Illuminated - Solder Lug - Panel Mount. ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MTL206N from TE Connectivity / Alcoswitch Brand is panel mount double pole double throw (DPDT) toggle switch with On-On switch function and solder lug termination. The MTL206N has 6A 125V AC ratings and 4A 28V DC ratings. This switch comes with non-illuminated 17mm long locking lever actuator and epoxy sealed terminals. Operating temperature range is from -20°C to 80°C.

Product Highlights:

  • MTL Series
  • Double Pole - Double Throw Configuration (Pole-Throw)
  • Current Rating = 6 Amps.
  • Mount Style = Panel
  • Termination Type = Vertical, Wire Lugs

Search Keywords: MTL206N

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
MTL206N
RoHS:
Yes
HTS:
8536509065
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
Pack
Pole Throw Configuration:
2P2T (DPDT)
Switch Configuration:
On None On
Contact Rating @ Voltage:
6@125VAC A
Actuator Style:
Locking Lever
Mounting:
Panel Mount with Threads
Thread Size:
1/4-40
Body Orientation:
Straight
Terminal Type:
Solder
Dimension:
13 x 13 x 40 mm
Operating Temperature:
-20 to 80 °C

IN STOCK: 0

On Order: 300   can ship 2/25/26

Factory Lead-Time 56 Weeks

Price (CAD)

Qty
Unit Price
1
$27.717
10
$23.857
25
$22.877
50
$22.158
100
$22.051
300
$21.944
500 +
$21.822
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
