PKD70B1/4 by te connectivity / alcoswitch brand
Image is representational - see mfr. specs

PKD70B1/4

TE Connectivity / Alcoswitch Brand

Switch Access Rotary Switch Round Knob ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

PKD70B1/4 is a molded phenolic control knob featuring a straight knurl surface with a spun aluminum inlay and black arrow indicator. This knob is designed for 1/4-inch shaft applications and includes a No. 6-32 set screw for secure mounting. The dimensional specifications include an overall diameter (A) of 1.02 inches (25.9 mm), a body diameter (B) of 0.750 inches (19.1 mm), and a skirt diameter (C) of 0.700 inches (17.8 mm), with a shaft depth (D) of 0.080 inches (2.0 mm). The knob features a spun aluminum inlay for enhanced durability and a black arrow indicator for precise position marking. This knob is commonly used in industrial control panels, test equipment, and consumer electronics where reliable shaft control and clear position indication are required.

Product Highlights:

  • Knob
  • Straight Knurl Knob Design
  • Indicator Style = Arrowhead
  • Indicator Location = On Skirt
  • With Skirt

Search Keywords: PKD70B14

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / Alcoswitch Brand
Part No:
PKD70B1/4
Alias/AKA:
3-1437624-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
3926902500
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Pack
Type:
Round Knob
Switch Type:
Rotary Switch
Color:
N/A

IN STOCK: 1,371

Can Ship immediately

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 9 Weeks

Price (USD)

Qty
Unit Price
25
$3.66
100
$3.54
250
$3.29
500
$3.10
1,000
$2.78
2,500
$2.26
5,000
$2.19
7,500 +
$2.16
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides
