103946-1 by te connectivity / amp brand
Image is representational - see mfr. specs

103946-1

TE Connectivity / AMP Brand

8X2 MTE SHRD PIN SR POL .100CL ...

Datasheet
RoHS Non-Compliant
Tube Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

103946-1 is a single-row IDC pin assembly from the TE Connectivity AMPMODU MTE interconnect system, designed for wire-to-board and wire-to-wire applications. This connector features insulation displacement contact (IDC) technology and supports 22-26 AWG wire sizes, with a current rating of 3 amps maximum per single contact in free air and an operating voltage of 267 V. The system operates over a temperature range of -65°C to +105°C and is available in multiple plating options including gold and matte tin. Common applications include computers, copiers, commercial printers, appliances, medical equipment, and automotive controls where reliable interconnection is required.

Product Highlights:

  • Pin Assemblies
  • Wire Termination Type = Crimp, Insulation Displacement Crimp (IDC)
  • Number of Positions = 2
  • Number of Rows = Single
  • Terminate To Wire

Search Keywords: 1039461

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
103946-1
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536698000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
72
Package Type:
Tube
Type:
IDC Connector
Body Orientation:
Straight
Gender:
Pin
Mounting:
Cable Mount
Pitch:
2.54 mm
Number of Contacts:
2
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3/Contact A
Termination Method:
IDT
Operating Temperature:
-65 to 105 °C
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 4,186

Can Ship immediately

Minimum Order Quantity: 72

Multiple: 72

Factory Lead-Time 42 Weeks

Price (USD)

Qty
Unit Price
72
$1.280
144
$1.255
288
$1.230
504
$1.209
1,008
$1.183
2,520
$1.149
5,040
$1.021
7,560 +
$1.007
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

58336-1

Crimp Tool Die - AMPMODU MTE Connectors - Tyco 58074-1 Manual Handle Assembly.

843477-1

Extraction Tool - MOD IV - IV.v or MOD V Contacts - Te Connectivity / Amp 843.
