1-102162-1 by te connectivity / amp brand
Image is representational - see mfr. specs

1-102162-1

TE Connectivity / AMP Brand

060 UNIV HDR RA 4S 30DP STD ...

Datasheet
RoHS Non-Compliant
Box Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1-102162-1 is a universal ejection pin header connector designed for ribbon and flat flex wire applications. It features 60 positions arranged in a matrix configuration with a 2.54 × 2.54 mm centerline spacing and right-angle PCB mounting. The connector incorporates a shrouded 4-sided housing made of thermoplastic material with UL 94V-0 flammability rating, gold-plated contact mating areas over nickel, and tin-lead over nickel plating on solder posts. With a post size of 0.64 mm and solder tail length of 3.94 mm, it supports wave solder processes up to 265°C and is compatible with 3.18 mm PCB thickness. This connector is ideal for high-density interconnect applications in data acquisition systems, instrumentation, and industrial equipment requiring reliable, polarized connections.

Search Keywords: 11021621

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-102162-1
Unit of Measure:
Per Each
RoHS:
No
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
30
Package Type:
Box
Type:
Ejector Header
Body Orientation:
Right Angle
Gender:
HDR
Mounting:
Through Hole
Pitch:
2.54 mm
Number of Contacts:
60
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
Solder
Operating Temperature:
-65 to 105 °C
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 64

Ships today, if you order in

MOQ for In Stock Qty: 30

MOQ for out of Stock Qty: 30

Factory Lead-Time 21 Weeks

Price (USD)

Qty
Unit Price
30
$16.71
60
$16.67
120
$10.26
180
$8.12
240 +
$7.95
