1-111446-6

TE Connectivity / AMP Brand

16 UNIV I/O, NO EARS,LEAD FREE ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1-111446-6 is a 16-position ribbon cable connector header without latches, designed for cable-to-board interconnect applications. The connector features a black thermoplastic housing rated UL 94V-0, stainless steel latches, and phosphor bronze contacts plated with 30 microinch gold over nickel with tin in the termination area. It has dimensions of A: 1.292 inches (32.82 mm) and B: 1.372 inches (34.85 mm), with a contact pitch of .100 inches (2.54 mm) and cable pitch of .050 inches (1.27 mm). The connector mates with posts measuring .015 inches (0.38 mm) square, .125 inches (3.18 mm) long, on a .050 x .100 inch (1.27 x 2.54 mm) grid. This RoHS compliant connector is ideal for ribbon cable interconnect solutions in electronic assemblies requiring reliable board-to-cable connections.

Product Highlights:

  • Connector Type = Universal I/O
  • Number of Positions = 16
  • Plug
  • Without Mating Polarization
  • Terminate To Ribbon Cable

Search Keywords: 11114466

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-111446-6
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
90
Package Type:
Tray
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
PL
Mounting:
Cable Mount
Pitch:
2.54 mm
Number of Contacts:
16
Maximum Voltage Rating:
N/A
Maximum Current Rating:
1/Contact A
Termination Method:
IDT
Operating Temperature:
-65 to 105 °C

IN STOCK: 1,138

Can Ship immediately

Minimum Order Quantity: 5

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
1
$14.570
5
$13.246
25
$8.807
90
$7.612
180
$7.262
270
$7.128
540
$6.922
1,080
$6.458
2,520 +
$6.427
Suppliers Standard Package
