1-1337481-0 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1-1337481-0

The 1-1337481-0 is a board-mount, right-angle SMB/Type 43 jack RF connector with a snap-on coupling mechanism. ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 1-1337481-0 is a subminiature, board-mount, right-angle jack from the SMB/Type 43 connector series. This connector operates over a frequency range of DC to 4 GHz and is compatible with both 50 and 75-ohm impedance systems. It features a snap-on coupling mechanism and provides a maximum VSWR of 1.20 up to 4 GHz. The component is rated for 500 mating cycles and can operate in a wide temperature range from -65°C to +165°C. As a smaller alternative to SMA connectors, it is well-suited for applications such as GPS, telephony, and CATV systems.

Product Highlights:

  • Connector
  • Jack
  • Standard
  • Terminate To Printed Circuit Board
  • Coupler Style = Snap-On

Search Keywords: 113374810

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-1337481-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BAG
Type:
SMB
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
14.5 x 6.35 x 7.1 mm

IN STOCK: 801

Ships today, if you order in

On Order: 1,250   can ship 3/1/27

Minimum Order Quantity: 5

Factory Lead-Time 50 Weeks

Price (USD)

Qty
Unit Price
5
$6.83
25
$5.57
100
$5.09
250
$4.75
500
$4.52
1,000
$4.41
2,500
$4.40
5,000 +
$4.39
Log in for special pricing
