1-1375820-0 by te connectivity / amp brand
Image is representational - see mfr. specs

1-1375820-0

TE Connectivity / AMP Brand

CST-100 II HOUSING 10 POS ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1-1375820-0 is a 10-position MTA-100 series connector housing designed for wire-to-board interconnect applications. The housing is manufactured from UL 94V-0 rated nylon in white color and features a 0.100" (2.54 mm) centerline spacing with a dimension A of 1.020" (25.91 mm). It is compatible with 22–26 AWG wire range (0.35–0.13 mm²) and accepts contacts with maximum insulation diameter of 0.065" (1.65 mm). This connector housing is commonly used in printed circuit board applications where reliable wire-to-board connections are required, offering RoHS compliant materials for environmental compliance.

Product Highlights:

  • CST-100 II Housings
  • Number of Positions = 10
  • Mating Type = Receptacle
  • Wire-to-Board Application
  • 2.54 mm Contact Centerline Spacing

Search Keywords: 113758200

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-1375820-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Pack
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
RCP
Number of Contacts:
10
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
4/Contact A
Operating Temperature:
-55 to 105 °C

IN STOCK: 27,116

Ships today, if you order in

Minimum Order Quantity: 100

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
100
$0.3620
500
$0.3249
1,000
$0.2913
2,500
$0.2804
5,000
$0.2789
7,500
$0.2776
10,000
$0.2693
15,000 +
$0.2680
