1-1469491-3

TE Connectivity / AMP Brand

The 1-1469491-3 is a right-angle, 90° keyed VITA 46 guide module used for aligning daughter cards in backplane systems. ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1-1469491-3 is a right-angle VITA 46 guide module designed to ensure proper alignment in board-to-board connections. This die-cast module features 90° keying to prevent the mis-mating of daughter cards and has a silver-plated finish. It is designed for a vertical pin with an 11.6 mm thread depth and offers a gatherability of +/-3.5 mm. Meeting the VITA 46 specification, this RoHS compliant guide module is essential for reliable blind-mating in backplane and co-planar interconnection systems.

Product Highlights:

  • Pin, External Thread
  • Guidance Series
  • VITA 41/VITA 46 Configuration
  • Used With 9mm Guide Module
