1-1478035-0 by te connectivity / amp brand
Image is representational - see mfr. specs

1-1478035-0

TE Connectivity / AMP Brand

BNC ELBOW PCB SOCKET SILVER PLT 50 OHM ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1-1478035-0 is a BNC RF connector jack designed for printed circuit board applications. This professional-grade connector features a right-angle (elbow) body style with solder tail pin retention for secure PCB mounting. The jack configuration with straight mounting post style provides reliable RF signal transmission. It is suitable for applications requiring robust RF connectivity on PCBs, such as test equipment, communication systems, and instrumentation.

Product Highlights:

  • Connector
  • Connector Type = BNC
  • Jack
  • Terminate To Printed Circuit Board
  • Body Style = Elbow

Search Keywords: 114780350

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-1478035-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1
Package Type:
Bag
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
RCP
Mounting:
Through Hole
Body Orientation:
Right Angle
Terminate To:
PCB
Termination Method:
Solder
Operating Temperature:
-65 to 165 °C
Dimension:
22.4 x 18.6 x 11 mm
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 826

Can Ship immediately

Minimum Order Quantity: 3

Price (USD)

Qty
Unit Price
3
$10.90
100
$9.56
500
$6.99
1,000
$6.92
2,000
$6.85
3,000
$6.78
5,000
$6.71
10,000 +
$6.63
Log in for special pricing Click for Quote Price Match Request
