1-1478403-0

BNC STRAIGHT PLUG SOLDER (PS) 75 OHM RG179B/U, 187A/U, URM111 ...

View Datasheet Ask the Datasheet
RoHS Compliant
Carton Packaging
Accessories
Discontinued
Certificate of Compliance

DESCRIPTION

The 1-1478403-0 is a BNC straight plug RF connector designed for terminating 75 ohm coaxial cables using solder or clamp methods. It features a silver-plated brass center contact and silver body plating, with compatibility for multiple coaxial cable types including RG-179B, RG-187A, and various Raychem cable variants. The connector operates across a frequency range of DC to 2 GHz and maintains performance at operating temperatures up to 165°C, making it suitable for demanding RF applications. It is RoHS and ELV compliant and supports wave solder processes at temperatures up to 265°C. This connector is commonly used in RF signal distribution, test equipment, and communication systems where reliable impedance matching and signal integrity are essential.

Search Keywords: 114784030

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-1478403-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694010
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
Carton
Type:
BNC
Impedance:
75 Ohm
Operating Frequency:
0 to 2 Hz to GHz
Gender:
PL
Mounting:
Cable Mount
Body Orientation:
Straight
Terminate To:
Coaxial Cable
Termination Method:
Solder
Operating Temperature:
N/A
Dimension:
26.1 x 14.5 mm
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 672

Can Ship immediately

Minimum Order Quantity: 20

Price (USD)

Qty
Unit Price
20
$3.29
85
$3.22
200
$3.16
350
$3.11
1,000
$3.04
2,500
$2.69
5,000 +
$2.34
