1-1546306-4

TE Connectivity / AMP Brand

14P.374" DR BARRIER STRIP ...

Datasheet
RoHS Compliant
Carton Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1-1546306-4 is a double row barrier strip terminal block designed for secure wire-to-wire or wire-to-board connections. This panel mount terminal block features a 0.374" centerline spacing, supports 2-30 circuits, and is rated for a maximum current of 20A and maximum voltage of 300V. It accepts wire sizes ranging from 12-22 AWG and is molded to length for precise fit. Common applications include machine controls, power supplies, test and measurement equipment, automation systems, and HVAC controls where reliable electrical connections are required.

Product Highlights:

  • Barrier Strip
  • Barrier Style = Double Row, Dual Barrier
  • Block Style = Flat
  • 9.53 mm Centerline
  • Vertical Mount Angle

Search Keywords: 115463064

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-1546306-4
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
TW
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
80
Package Type:
Carton
Type:
Barrier Strip
Mounting:
Cable Mount
Gender:
N/A
Termination Method:
Screw
Pitch:
9.53 mm
Number of Circuits:
14
Maximum Voltage Rating:
300 V
Maximum Current Rating:
20/Contact A
Wire Size:
12-22 AWG
Operating Temperature:
-40 to 120 °C

IN STOCK: 103

Ships today, if you order in

Minimum Order Quantity: 5

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
5
$6.17
80
$4.65
160
$4.43
320
$4.22
560
$4.20
1,040
$4.18
2,560
$4.16
5,040 +
$4.14
Suppliers Standard Package
