1-1658622-1 by te connectivity / amp brand
Image is representational - see mfr. specs

1-1658622-1

TE Connectivity / AMP Brand

A 60-position, center and military polarized Novo receptacle for terminating .050 inch pitch ribbon cable to a .100 x .100 inch grid. ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1-1658622-1 is a 60-position Novo receptacle connector designed for mass termination of ribbon cable in wire-to-board applications. It features a .100 x .100 inch centerline grid and provides both center and military polarization options. The contacts have Duplex² plating, which includes a minimum of .000030 inches of gold or gold flash over palladium-nickel on the mating end and tin on the termination end, all over a nickel underplate. This preassembled connector utilizes a military-approved tuning fork contact design for reliable interconnection with .025 inch square or round posts, making it ideal for various electronic equipment requiring a robust interconnect solution.

Product Highlights:

  • Connector Type = NOVO
  • 60 Positions
  • Receptacle
  • Mating Polarization Method = Center & Military
  • With Mating Polarization

Search Keywords: 116586221

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-1658622-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694051
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
27
Package Type:
Tray
Type:
IDC Connector
Body Orientation:
Right Angle
Gender:
RCP
Mounting:
Cable Mount
Pitch:
2.54 mm
Number of Contacts:
60
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
1/Contact A
Termination Method:
IDT
Operating Temperature:
-65 to 105 °C

IN STOCK: 810

Ships today, if you order in

MOQ for In Stock Qty: 27

MOQ for out of Stock Qty: 1350

Multiple: 27

Factory Lead-Time 7 Weeks

Price (USD)

Qty
Unit Price
27
$4.33
270
$3.78
513
$3.61
1,026
$3.44
1,350
$3.33
2,700
$3.22
4,050
$3.21
5,400 +
$3.20
Suppliers Standard Package
