1-174357-2

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

1-174357-2

RoHS:

Yes

HTS:

8538906000

COO:

JP

ECCN:

EAR99

Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.

100

Package Type:

Bag

Connector System:

Wire-to-Wire

UL Flammability Rating:

UL 94V-2

Nominal Voltage Architecture:

12 V

Connector Position Assurance Capable:

No

Serviceable:

Yes

Connector & Housing Type:

Housing for female terminals

Sealable:

Yes

Operating Voltage:

12 VDC

Primary Product Color:

Black

Number of Positions:

3

Packaging Quantity:

100

Number of Rows:

1

Primary Locking Feature:

Integrated in Housing

Circuit Application:

Signal

Packaging Method:

Bag

Terminal Position Assurance:

Yes

Cable Exit Angle:

180°

Operating Temperature Range:

-30 – 105 °C, -22 – 221 °F

Mating Tab Width:

.071 in, 1.8 mm

Operating Temperature (Max):

100 °C, 105 °C, 70 °C, 75 °C, 80 °C, 85 °C, 90 °C, 158 °F, 167 °F, 176 °F

Centerline (Pitch):

.189 in, 4.8 mm

Product Length:

1.087 in, 27.6 mm

Product Width:

1 in, 25.4 mm

Housing Material:

PBT

Connector Height:

.898 in, 22.8 mm

Contact Size:

1.8mm

Contact Type:

Receptacle

Strain Relief:

Without

Mating Alignment Type:

Polarization Slot

Mating Alignment:

With

Connector Shape:

Rectangular

Connector Mounting Type:

Cable Mount (Free-Hanging)
