1217642-1 by te connectivity / amp brand
Image is representational - see mfr. specs

1217642-1

TE Connectivity / AMP Brand

TAB, 059 SERIES, L.H. MAG-MATE ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1217642-1 is a MAG-MATE 300 Box standard IDC poke-in terminal designed for magnet wire termination in appliance applications. This terminal is manufactured from tin plated brass and features insulation displacement connection (IDC) technology for reliable magnet wire connections. The terminal is designed for use with copper magnet wire and accepts mating tabs with dimensions of .135 x .020 inches (3.40 x 0.50 mm). Common applications include appliance motor connections and other magnet wire termination requirements where reliable electrical connections are essential.

Search Keywords: 12176421

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1217642-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
US
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
20000
Package Type:
Reel
Type:
Tab Terminal
Gender:
Tab
Tab Size:
1.21 mm²
Stud Size:
N/A
Wire Size:
25-27 AWG
Color:
N/A
Operating Temperature:
N/A

IN STOCK: 80,000

Can Ship immediately

MOQ for In Stock Qty: 2500

MOQ for out of Stock Qty: 30000

Factory Lead-Time 4 Weeks

Price (USD)

Qty
Unit Price
2,500
$0.2242
7,500
$0.2237
10,000
$0.2231
30,000
$0.2226
60,000
$0.1174
90,000
$0.0808
120,000 +
$0.0792
Log in for special pricing Click for Quote Price Match Request
