1-2199298-5 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1-2199298-5

Conn DIP Socket SKT 18 POS 2.54mm Solder ST Thru-Hole Box/Tube ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

1-2199298-5 is an 18-position DIP socket with dual leaf contacts designed for reliable IC-to-PCB connections. The socket features dual leaf contacts that enlarge the contact area and ensure low and constant contact resistance, combined with a true closed bottom design that prevents solder and flux wicking. It utilizes 30% glass-filled PBT thermoplastic insulation (black), phosphorous bronze contacts with tin plating, and supports through-hole soldering with a 7.62 mm (300 CL) centerline spacing. The socket accommodates IC pins ranging from 0.008" to 0.012" diameter and provides a maximum insertion force of 300 grams with a minimum withdrawal force of 20 grams. This socket is ideal for applications requiring easy IC component testing, upgrade, and field replacement in industrial controls, medical devices, military systems, and embedded systems such as RFID door locks, elevator control boards, and CNC machine control systems.

Search Keywords: 121992985

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-2199298-5
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
2600
Package Type:
TUBE
Type:
DIP Socket3792
Body Orientation:
Straight3768
Mounting:
Through Hole3783
Gender:
SKT3772
Pitch:
2.54 mm
Number of Contacts:
18
Maximum Voltage Rating:
2503781VDC,2503781VAC
Maximum Current Rating:
1/Contact A
Operating Temperature:
-40 to 105 °C

IN STOCK: 1,600

Ships today, if you order in

Minimum Order Quantity: 250

Factory Lead-Time 6 Weeks

Price (USD)

Qty
Unit Price
250
$0.2166
1,000
$0.1510
2,600
$0.1472
5,200
$0.1432
7,800
$0.1407
26,000
$0.1404
52,000
$0.1400
101,400 +
$0.1397
Supplier's Standard Package
