1-338096-1 by te connectivity / amp brand
Image is representational - see mfr. specs

1-338096-1

TE Connectivity / AMP Brand

micro-match cosi contact ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1-338096-1 is a crimp-on contact component for the TE Connectivity Micro-MaTch connector system, specifically engineered for wire-to-board and board-to-board interconnections. The contact is rated for 28-24 AWG wire sizes with an inner diameter (ID) of 0.76-1.00 mm and features tin-plated contact design that provides gas-tight connections and fretting corrosion resistance. The contact incorporates a positioning spring mechanism in the female part that absorbs relative movements caused by vibrations and thermal expansion, preventing contact spot movement and maintaining connection integrity. These contacts are supplied on tape and are suitable for mass termination of ribbon cable, with availability in reel quantities of 15,000 or 750 pieces. The 1-338096-1 contact is widely used in automation and control applications including production equipment, robots, motors, heating systems, automotive electronics, and communication devices.

Product Highlights:

  • Contact
  • Terminate To Wire
  • Packaging Method = Reel
  • Packaging Quantity = 750
  • Wire Range = 0.08-0.24² [28-24] mm [AWG]

Search Keywords: 13380961

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-338096-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538908140
COO:
CH
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
750
Package Type:
Reel
Contact Type:
Stamped Signal
Gender:
Pin
Contact Size:
N/A
Wire Size:
24-28 AWG
Contact Material:
Phosphor Bronze
Contact Plating:
Pre-Tin
Maximum Current Rating:
N/A
Termination Method:
Crimp

IN STOCK: 11,250

Ships today, if you order in

Minimum Order Quantity: 750

Multiple: 750

Factory Lead-Time 20 Weeks

Price (USD)

Qty
Unit Price
750
$0.1355
1,500
$0.1276
3,000
$0.1223
5,250
$0.1161
10,500
$0.1135
25,500
$0.1132
50,250
$0.1129
100,500 +
$0.1127
Reel Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

734870-2

CRIMP HT, MICRO-MATCH COSI, AW

5-1579008-3

EXTRACTION TOOL
