1393114-1 by te connectivity / amp brand
Image is representational - see mfr. specs

1393114-1

TE Connectivity / AMP Brand

General Purpose Relay SPST-NO (DM) (1 Form X) 24VDC Coil Socketable ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The 1393114-1 is a general-purpose Panel Plug-in Relay with 24VDC coil. This relay has 1 form-X (1NO-DM) AgCdO contact. 4.75mm (0.187 inch) quick-connect terminal, socket mount with plain case. Class B coil insulation. Contact Voltage VDC: 150VDC Contact Material: Silver Cadmium Oxide Coil Resistance: 472ohm Enclosed relay with magnetic blow-outs -45 to 70°C Operating temperature range RT I Environmental protection rating Applications Industrial

Product Highlights:

  • KUEP Series
  • Contact Arrangement = 1 Form X, SPST-NO-DM, 1 N/O Bridge Contact
  • Contact Current Rating = 10 Amps.
  • Monostable Coil Magnetic System
  • Without Coil Suppression Diode

Search Keywords: 13931141

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1393114-1
Alias/AKA:
KUEP-3D15-24
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
25
Package Type:
Pack
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
SPST-NO-DM
Maximum Current Rating:
10 A
Mounting:
Plain Case
Termination Style:
0.187Quick Connect/Solder
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-45 to 70 °C
Coil Resistance:
472 Ohm

IN STOCK: 93

Ships today, if you order in

On Order: 450   can ship 8/3/26
On Order: 1,038   can ship 9/21/26
On Order: 1,050   can ship 10/5/26

Factory Lead-Time 25 Weeks

Price (USD)

Qty
Unit Price
1
$44.69
5
$41.26
10
$39.28
25
$36.14
50
$35.18
100
$34.86
250 +
$33.33
Suppliers Standard Package
