1432772-1 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1432772-1

Power Relay 12VDC 40A SPST-NO(26.5mm 31.6mm 38.4mm) Plug-In ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
Certificate of Compliance

DESCRIPTION

1432772-1 is an electromechanical relay featuring a 1 Form A (SPST) contact arrangement for high-current switching applications. It operates with a maximum operate voltage of 7.8 VDC and a minimum release voltage of 1.2 VDC, with a coil resistance of 90 Ohms ±10%. The relay supports a maximum continuous current of 40A at 23°C (35A at 85°C) and features AgSnO (Silver Tin-Oxide) contact material with a millivolt drop of 200mV at 35A. Operating over a temperature range of -40°C to +85°C, it offers an expected electrical life of 100,000 operations at 40A, 14 VDC resistive load and a mechanical life of 10 million operations without contact load. This relay is suitable for industrial and commercial power switching applications requiring reliable high-current performance.

Search Keywords: 14327721

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1432772-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
100
Relay Construction:
Non-Latching10725
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO10703
Mounting:
Plug-In10716
Termination Style:
Quick Connect10727
Push to Test Button:
No10724
Led Indicator:
No10708
Operating Temperature:
-40 to 85 °C
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 5,079
