1432782-1 by te connectivity / amp brand
Image is representational - see mfr. specs

1432782-1

TE Connectivity / AMP Brand

Electromechanical Relay 12VDC 90Ohm 35A SPST-NO (26.5x26.5x36)mm Plug-In General Purpose Relay ...

Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1432782-1 is a 12 VDC electromechanical relay designed for high-current switching applications. It features a 1 Form A (SPST) contact arrangement with AgSnO (silver tin-oxide) contact material, providing a maximum continuous current of 40A at 23°C and a maximum make current of 90A for lamp loads. The relay operates with a nominal coil voltage of 12 VDC, a coil resistance of 90 Ohms ±10%, and an operating temperature range of -40°C to +85°C. With an operate time of 8 ms maximum and release time of 5 ms maximum, this relay offers reliable switching performance with an expected electrical life of 100,000 operations at 40A, 14 VDC resistive load. Common applications include automotive systems, industrial controls, and power distribution circuits requiring robust high-current switching capability.

Search Keywords: 14327821

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1432782-1
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490080
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO
Maximum Current Rating:
35 A
Mounting:
Connector
Termination Style:
Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 568

Ships today, if you order in

Minimum Order Quantity: 5

Price (USD)

Qty
Unit Price
5
$3.032
50
$2.720
100
$2.696
300
$2.676
500
$2.663
1,000
$2.649
2,500
$2.636
5,000 +
$2.622
Suppliers Standard Package
