Image is representational - see manufacturer specifications

TE Connectivity / AMP Brand Authorized Distributor

1-480287-0

Name: 1-480287-0
Brand: Te Connectivity Amp Brand
SKU: 10183071
Price: 32.2 USD
Availability: InStock

12P CMNL PLUG HSG M/M NATL ...

View Datasheet

Ask the Datasheet

RoHS Compliant

BAG Packaging

Certificate of Compliance

DESCRIPTION

1-480287-0 is a 12-circuit dual row socket housing (plug) designed for use in Commercial MATE-N-LOK wire-to-board connector systems. This motor mount positive lock housing features UL94V-2 flammability rated nylon material in natural color and accepts double wire applications where individual insulation diameters do not exceed 0.115 inches (2.92 mm). The housing has dimensions of E: 1.290 inches (32.77 mm) and F: 1.195 inches (30.35 mm), with a 0.200 inch (5.08 mm) centerline spacing. It mates with pin housing (cap) part number 1-480288-0 and is compatible with pre-tin duplex plated PC board headers. This RoHS compliant connector is ideal for power circuit applications in home appliances and industrial equipment requiring reliable wire-to-board connections.

Product Highlights:

Housing
Contact Diameter = 2.13 mm
Number of Circuits = 12
4.95 x 9.14 mm Centerline, Matrix
Double-Row Contact Layout

Potential Applications:

Search Keywords: 14802870

SPECIFICATIONS

Product Attribute

Attribute Value

Select Attribute

Products found: 0

Supplier:

TE Connectivity / AMP Brand

Part No:

1-480287-0

Unit of Measure:

Per Each

RoHS:

Yes

HTS:

8538906000

COO:

ECCN:

EAR99

Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.

The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.

Package Type:

BAG

Mounting:

Cable Mount

Body Orientation:

Straight

Gender:

Number of Contacts:

Maximum Voltage Rating:

250,250 VDC|VAC

Maximum Current Rating:

13/Contact A

Operating Temperature:

-55 to 105 °C
