1-480720-0 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1-480720-0

2 Position Rectangular Housing Connector Plug Natural 0.200" (5.08mm) ...

View Datasheet Ask the Datasheet
RoHS Compliant
BAG Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The 1-480720-0 is a 2-way 1-row natural color free-hanging Socket Housing (plug) made of nylon. It is ideal for use with commercial MATE-N-LOK connectors and pin (cap) housing. UL94V-2 Flammability rating 250VAC Operating voltage -55 to 105°C Operating temperature range Connector Type Plug Contact Type Female Socket Number of Positions 2 Pitch 0.200" (5.08mm) Number of Rows 1 Mounting Type Free Hanging (In-Line) Contact Termination Crimp Fastening Type Latch Lock Color Natural Applications Commercial

Product Highlights:

  • Housing
  • Contact Diameter = 2.13 mm
  • Number of Circuits = 2
  • 5.08 mm Centerline, Matrix
  • In-Line Contact Layout

Search Keywords: 14807200

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-480720-0
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8538906000
COO:
MX
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1
Package Type:
BAG
Mounting:
Cable Mount
Body Orientation:
Straight
Gender:
PL
Number of Contacts:
2
Maximum Voltage Rating:
250 VAC
Maximum Current Rating:
13/Contact A
Operating Temperature:
-55 to 105 °C

IN STOCK: 4,478

Ships today, if you order in

On Order: 15,000   can ship 2/10/27

Minimum Order Quantity: 50

Factory Lead-Time 22 Weeks

Price (USD)

Qty
Unit Price
50
$0.6151
250
$0.4263
1,000
$0.4222
2,500
$0.4181
5,000
$0.4170
7,500
$0.4160
10,000
$0.4150
15,000 +
$0.4140
Log in for special pricing

Tools/3D Models

Product Guides

Product Changes

Accessories

1586530-2

02P CMNL HDR ASSY SHORT LF

350539-1

02P CMNL HDR ASSY SHORT NATL

350539-2

02P CMNL HDR ASSY SHORT NATL

350540-1

02P CMNL HDR ASSY LONG NATL

794012-1

Connector Housing - Commercial MATE-N-LOK Series - Receptacle - 2 Positions - 5.08 mm.

Show 3 More
