1-5225398-5 by te connectivity / amp brand

1-5225398-5

TE Connectivity / AMP Brand

DUAL CRIMP BNC BLKHD JACK ...

Datasheet
RoHS Compliant
Bag Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The part 1-5225398-5 is a versatile Dual Crimp BNC Blackhead Jack connector from TE Connectivity / AMP Brand. This compact and high-quality connector provides secure and reliable connections for your BNC cables. It features a dual crimp design, ensuring excellent signal transmission and minimizing signal loss. The blackhead jack enhances the aesthetic appeal and durability of the connector. With its reliable performance and sturdy construction, the part 1-5225398-5 is an excellent choice for a wide range of applications requiring BNC connections.

Product Highlights:

  • Connector
  • Connector Type = BNC
  • Jack
  • Terminate To Coaxial Cable
  • Coaxial Cable Termination Type = Crimp

Search Keywords: 152253985

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-5225398-5
RoHS:
Yes
HTS:
8536694010
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
Bag
Type:
BNC
Impedance:
50 Ohm
Operating Frequency:
0 to 4 Hz to GHz
Gender:
RCP
Mounting:
Panel Mount
Body Orientation:
Straight
Terminate To:
Coaxial Cable
Termination Method:
Crimp
Operating Temperature:
N/A
Dimension:
34.93 mm

IN STOCK: 676

Ships today, if you order in

MOQ for In Stock Qty: 5

MOQ for out of Stock Qty: 250

Factory Lead-Time 7 Weeks

Price (CAD)

Qty
Unit Price
5
$20.137
50
$18.130
100
$18.038
250
$17.947
500
$17.855
750
$17.763
1,000 +
$17.671
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes

Accessories

91904-1

Connector Accessories Coaxial Die Set RG 187
