1-5747150-3 by te connectivity / amp brand
Image is representational - see manufacturer specifications
TE Connectivity / AMP Brand Authorized Distributor

1-5747150-3

9 Position D-Sub Receptacle, Female Sockets Connector ...

View Datasheet Ask the Datasheet
RoHS Compliant
TUBE Packaging
Accessories
Certificate of Compliance

DESCRIPTION

TE Connectivity, the industry leader in AMPLIMITE D-Subminiature solutions, provides a complete range of quality, time-tested D-sub connectors that have become the standard in the D-Sub industry. TE Connectivity's complete line of D-Subminiature Connectors range from right-angle and vertical-posted connectors and cable connectors to the AMPLIMITE .050 Series D-Sub connectors. Connector Style D-Sub Connector Type Receptacle, Female Sockets Number of Positions 9 Number of Rows 2 Shell Size, Connector Layout 1 (DE, E) Contact Type Signal Mounting Type Through Hole Flange Feature Mating Side, Female Screwlock (4-40) Termination Solder Shell Material, Finish Steel, Tin Plated Contact Finish Gold Contact Finish Thickness Flash Material Flammability Rating UL94 V-0 Current Rating (Amps) 6A Operating Temperature -55°C ~ 105°C Voltage Rating 125V Color Black

Product Highlights:

  • Number of Positions = 9
  • Receptacle
  • PCB Mount Angle = Vertical
  • Product Series = HD 20
  • With Mating Connector Lock

Search Keywords: 157471503

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-5747150-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
17
Package Type:
TUBE
Type:
D-Subminiature
Body Orientation:
Straight
Mounting:
Through Hole
Gender:
SKT
Termination Method:
Solder
Shell Size:
1
Number of Contacts:
9
Contact Plating:
Gold over Nickel
Operating Temperature:
-55 to 105 °C

IN STOCK: 62

Can Ship immediately

On Order: 1,071   can ship 5/24/27

Minimum Order Quantity: 17

Multiple: 17

Factory Lead-Time 40 Weeks

Price (USD)

Qty
Unit Price
17
$3.87
51
$3.86
102
$3.82
255
$3.79
510
$3.78
1,003
$3.77
2,516 +
$3.76
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

1-747944-6

KIT,PLUG,9P,HDE,SHLD ENCLSRE

2-745492-0

PLUG ASSY,9P,HDE,MS

1571650-4

LF PLUG KIT,SIZE 1,7.2MM

1571650-6

LF PLUG KIT,SIZE 1,10.8MM

1571650-5

LF PLUG KIT,SIZE 1,9.5MM

Show 3 More
