1-5750913-9 by te connectivity / amp brand
Image is representational - see mfr. specs

1-5750913-9

TE Connectivity / AMP Brand

100 50SR CABLE CONN KIT ...

Datasheet
RoHS Compliant
KIT Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1-5750913-9 is a 100-position AMPLIMITE .050 Series cable plug connector designed for wire lacing termination applications. This high-density D-sub connector features a compact .050 x .100 inch (1.27 x 2.54 mm) centerline grid spacing and is configured for gray outer wire diameter (.029-.031 inch / 0.74-0.89 mm). The connector housing and covers are made from thermoplastic with 94V-0 flammability rating, while contacts are phosphor bronze with duplex plating featuring minimum .000030 inch (0.00076 mm) gold on the mating end and tin on the termination end, all underplated with nickel. The shell is steel plated with tin-nickel alloy over nickel over copper. Recommended wire sizes are 28 AWG (0.08-0.09 mm²) or 30 AWG (0.05 mm²), solid or 7 strand. This connector requires a backshell kit for complete assembly and is ideal for data and device interconnect applications requiring reliable, high-density connections.

Product Highlights:

  • Connector
  • Plug
  • Number of Positions = 100
  • Wire/Cable Type = Round Jacketed Cable
  • Wire Range = 0.05-0.09² [30-28] mm [AWG]

Search Keywords: 157509139

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1-5750913-9
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
7
Package Type:
KIT
Type:
SCSI
Body Orientation:
Right Angle
Mounting:
Cable Mount
Gender:
PL
Termination Method:
IDT
Pitch:
1.27 mm
Number of Contacts:
100
Maximum Voltage Rating:
30 VAC
Maximum Current Rating:
1/Contact A
Operating Temperature:
-55 to 105 °C

IN STOCK: 0

Minimum Order Quantity: 7

Multiple: 7

Factory Lead-Time 13 Weeks

Price (USD)

Qty
Unit Price
7
$21.53
14
$20.54
28
$19.92
56
$19.34
105
$18.28
252
$17.80
504 +
$15.37
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
