1586315-3 by te connectivity / amp brand
Image is representational - see mfr. specs

1586315-3

TE Connectivity / AMP Brand

VAL-U-LOK SKT PHBZ SN 24-18 LP ...

Datasheet
RoHS Compliant
Pack Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

1586315-3 is a loose-piece socket contact for Mini-Universal MATE-N-LOK connectors, engineered for wire-to-board interconnection applications. This contact is specified for 22-18 AWG wire sizes with an insulation diameter range of 0.060 to 0.122 inches (1.52 to 3.10 mm), and features phosphor bronze material with pre-tin plating finish. The contact is compatible with the PRO-CRIMPER III hand tool (part number 91388-1) and applicator (part number 1852668-X) for reliable crimping and assembly. These socket contacts are commonly used in automotive, industrial control, and consumer electronics applications where robust, repeatable wire terminations are required, offering excellent electrical conductivity and mechanical durability in compact connector systems.

Product Highlights:

  • Contact
  • Socket
  • Wire Range = 0.30-0.90² [22-18] mm [AWG]

Search Keywords: 15863153

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
TE Connectivity / AMP Brand
Part No:
1586315-3
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Package Type:
Pack
Contact Type:
Signal
Gender:
SKT
Contact Size:
N/A
Wire Size:
18-22 AWG
Contact Material:
Phosphor Bronze
Contact Plating:
Pre-Tin
Maximum Current Rating:
9 A
Termination Method:
Crimp

IN STOCK: 19,000

Ships today, if you order in

Minimum Order Quantity: 500

Multiple: 500

Factory Lead-Time 15 Weeks

Price (USD)

Qty
Unit Price
500
$0.0599
2,500
$0.0528
5,000
$0.0527
7,500
$0.0517
25,000
$0.0503
50,000
$0.0502
100,000
$0.0451
150,000 +
$0.0450
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

91388-1

PRO-CRIMPER TOOL & DIE

91388-2

Tools and Accessories, Die Set for Crimping Tool Size 16

1586343-1

Tool Extraction PE Series Connector System

2-1579021-8

CSV10 4.2 ConnSyst

Show 2 More
